SUPERFLEX PU PLUS HMR DIN 4102-B1 AS

912887

POLYURETHANE (PU) hose with galvanised steel spiral, for suction and transport of dust, chips and abrasive material.

Back to Superflex Series

Details

Smooth surface

Flexibility

Abrasion Resistance

Temperature range

-40 °C 90 °C

Chemical Resistance

PU Table

Crushing Resistance

Ozone Resistance

Flame Retardant

According to DIN -4102 IN B1 class

Antistatic

R ≤ 109Ω

ATEX

According to Declaration

O-Phtalate Free

Phtalate Free

Documents

Information presence SVHC substances

RoHS Declaration

“Conflict Mineral” Declaration

“USA TSCA” Declaration

Ø nominal mm	Ø nominal inch	Ø i.d. mm	Ø o.d. mm	working pressure at 23 °C bar	vacuum 23 °C m/H₂O	bending radius mm	wall thickness mm	Ø steel wire mm	spiral pitch mm	spiral direction	weight meter g/m	coil length m	Availability
30		30.5	39	3.3	9	60	1.3	1,4x1,8	13	left	320	20	In stock
32	1 1/4	32.5	41	3.1	9	65	1.3	1,4x1,8	13	left	350	20	In stock
35		35.5	44	2.8	9	70	1.3	1,4x1,8	13	left	400	20	In stock
38	1 1/2	38.5	47	2.7	9	75	1.3	1,4x1,8	13	left	440	20	In stock
40		40.5	49	2.6	8	80	1.3	1,4x1,8	13	left	460	20	In stock
45	1 3/4	45.5	54	2.4	8	90	1.3	1,4x1,8	13	left	560	20	In stock
50	2	50.5	60	2.2	8	100	1.4	1,6x2	14	left	620	20	In stock
55		55.5	65	2	7	110	1.4	1,6x2	14	left	680	20	In stock
60		60.5	70	1.8	7	120	1.4	1,6x2	14	left	720	20	In stock
63	2 1/2	63.5	73	1.7	7	130	1.4	1,6x2	14	left	750	20	In stock
65		65.5	75	1.7	7	130	1.4	1,6x2	14	left	800	20	In stock
70		70.5	80	1.6	5	140	1.45	1,8x2,2	15	left	950	20	In stock
76	3	76.5	86	1.5	5	150	1.45	1,8x2,2	15	left	1000	20	In stock
80		80.5	90	1.4	5	160	1.45	1,8x2,2	15	left	1050	20	In stock
90	3 1/2	90.5	100	1.2	5	180	1.45	1,8x2,2	15	left	1150	20	In stock
100		100.5	111	1.1	4	200	1.5	2x2,5	16	left	1350	15	In stock
110		110.5	121	1	4	220	1.5	2x2,5	16	left	1450	15	In stock
115		115.5	126	1	4	230	1.5	2x2,5	16	left	1550	15	In stock
120		120.5	131	0.9	4	240	1.5	2x2,5	16	left	1630	15	In stock
127	5	127.5	138	0.9	3	260	1.5	2x2,5	16	left	1800	15	In stock
130		130.5	141	0.8	3	270	1.5	2x2,5	16	left	1850	15	In stock
140		140.5	151	0.8	3	280	1.5	2x2,5	18	left	1900	15	In stock
150		150.5	161	0.8	3	300	1.5	2x2,5	18	left	2050	15	In stock
160		160.5	171	0.8	2	320	1.5	2x2,5	18	left	2200	15	In stock
175		175.5	186	0.7	2	350	1.5	2x2,5	18	left	2350	10	In stock
180		180.5	191	0.7	2	360	1.5	2x2,5	18	left	2450	10	In stock
200		201	212	0.6	2	400	1.6	2,5x3	19.8	left	3200	10	In stock
250		251	262	0.5	2	500	1.6	2,5x3	20.5	left	3800	10	In stock
300		301	312	0.4	2	600	1.6	2,5x3	22	left	4500	10	In stock
350		352	366	0.3	1.8	700	1.8	3x3,5	25	left	6000	10	In stock
400		402	416	0.2	1.2	800	1.8	3x3,5	24.5	left	7000	10	In stock

All technical specifications apply to a temperature of 23° C ± 2° C (ISO 291)
The tolerance on all specifications ±5% (Tolerance Percentage is applicable on ALL DATA across our range)
